Fly Savanna 3 Frame
Fly Savanna 3 Frame
-
The Courage Adams signature Savanna frame sticks with its original geometry, but utilises new tubing specs that help reduce the overall weight of the frame without sacrificing any of the strength. The frame features internal and external gussets, multi-butted and tapered tubing, an Investment Cast seat post clamp with the Horizontal Cut System and Investment Cast Dropouts with integrated chain tensioners. It is brakeless, so there are no mounts or guides.
-
Seen this cheaper elsewhere? We price match any legitimate competitor! For a price match to be accepted, the item has to be identical and be in stock and available for purchase at our competitor. We will notify you by email of the decision when reviewed within 24hours but usually much sooner
-
- Free UK Shipping On Orders Over £99.99*
- Complete Tracking On All Orders
- 90 Day Returns Policy
- Free Gifts With All orders
- *Excludes bulky items
Product Specs
- MATERIAL: 4132 Chromoly
- HEAD TUBE ANGLE: 75.5°
- SEAT TUBE ANGLE: 71°
- CHAIN STAY LENGTH: 13"
- BB HEIGHT: 11.75"
- WHEEL SIZE: 20"
- STANDOVER HEIGHT: 9.25"
- DROPOUT SIZE: 14mm
- HEADSET TYPE: Integrated
- BB TYPE: Mid
- BRAKE MOUNTS: N/A
- GYRO TABS: N/A
- WEIGHT: 5.3lbs
Product Highlights
- Responsive Geometry with Short Backend and Steep Headtube
- Best suited to Street and Park riding
- High-quality Chromoly construction
- Gusseted tubing for added strength
- Built in chain tensioners
UNDERSTANDING FRAME GEOMETRY
BMX frame geometry can look daunting, but thanks to our handy guide below you will have it figured out in no time. Remember, we're all BMXers here so if you have any questions just ask.
Keep reading to find your perfect frame, or click below to watch the buyers guide video.
FRAME SIZE CHART
Frame sizing is very much a personal preference: some riders like them longer, others shorter. Here's a rough guide - if you have any questions remember we are here to help!3ft - 3ft 8" - best suited to a 16" BMX bike
3ft 8" - 4ft - best suited an 18" BMX bike
4ft - 5ft - 18" to 20" top tube
5ft - 5ft 4" - 20" to 20.25" top tube
5ft 4" - 5ft 8" - 20.25" to 21" top tube
5ft 8" - 6ft - 21" to 21.25" top tube
6ft plus - 21" top tube or longer
Rider Height (in) | Rider Height (cm) | Top Tube Length |
---|---|---|
5' | 152 | 20" |
5'3" | 160 | 20.5" |
5'6" | 167 | 20.75" |
5'9" | 175 | 21" |
6' | 182 | 21.25" |
6'6" | 200 | 21.5" |
FRAME GEOMETRY
Frame geometry can take a bit of understanding - but here at SourceBMX we are here to help! The first thing to understand is that BMX frame sizing is best measured by the length of the top tube - shown here as TT. Keep reading on to understand how the angles change how your frame will feel!![](http://www.sourcebmx.com/cdn/shop/files/frame-geometry.jpg?v=1684144736)
